Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm

Introducing our Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm. We are a factory specializing in textile machinery production.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Detailed Photos
  • Product Parameters
  • Our Advantages
  • FAQ
Overview

Basic Info.

Model NO.
JLH9200
Customized
Customized
Condition
New
After-sales Service
1 Year
Textile Machine
Weaving Machine
Machine Working Width
190cm-280cm
Take up
Electronic
Mainly Used for
Light and Medium Density Fabric
Let off
Electronic
Shedding
Dobby/Cam/Jaquard
Dobby
Staubli
Weft Selection
2c, 4c, 6c
Weft Density
25-150pick/Inch
Transport Package
Bulk
Trademark
JINLIHUA
Origin
Qingdao, China
HS Code
8446305000
Production Capacity
1500 Sets / Year

Product Description

Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm

Qingdao Jin Lihua Textile Machinery Co.
  JINLIHUA's textile machinery business will constantly explores the future of the textile industry by providing products with the high productivity and quality while also implementing active environmental policies including energy conservation and reduction of waste pollution, and providing detailed, attentive service.



Product Description

Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm
    The "JLH9200" upgrades the high-speed ability of the predecessors. The JLH9200 has the advantages of improved stability, long service life and increased accuracy. It is an advanced air jet loom that saves resources, energy, and manpower.

    The "JLH9200" is a high performance weaving air jet loom for new era.we provided Newly upgraded electric components and Integrated high technology to support weaving, the JLH9200 combines Mechatronics with high technology, which realizes the stable weaving of high quality textile.
Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm

Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm
Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm
Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm
From clothing to industrial materials, the "JLH9200" tend on balance to do well in a wide range of fabrics.


  *We sincerely hope to establish good business relationship with customers home and abroad, to cooperate frankly on the basis of mutual benefit, reliable quality products and favorable prices.

Detailed Photos


Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm
Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm

Strictly conducts ISO9001:2000 whole processing and quality control.


    New control system had an advanced technology, a high level of security, reliable quality, convenient operation, substantial increase in production efficiency. In addition, along with intelligent and automated service for modern technics being advanced continuously, our innovation for weaving industry having been optimized continually.
Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm
Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cm
    In pursuit of reliable and original technology, our technicians, accomplished in developing textile machines and relevent tool attachments, is working on new technology for advanced composite material.

Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cmStable operation, durable accessories and low damage rate
Air Jet Loom Textile Weaving Machine Space-Saving Machine 190cmWear-resistant, no rust, no static electricity, reduce warp yarn breakage

    *The large number of products offered in reliable quality, with global availability and technical expertise, provide a clear competitive edge in the global markets.

Product Parameters

Qingdao Jin Lihua Textile Machinery Co.

Raw material Combed yarn 7s-80s ,silk, polyester yarn
Respective fabric 100% cotton  60s x 60s  90x88(warp x weft density/inch)
(fabric width:178cm)
 Rayon    45s x 45s 100x80  178cm






Respective machine
      Reed width:190cm
          Shedding:Plain
          Electronic feeder:2 nozzle
          Single warp beam
          Electronic let off and take up ELO& ETU
          Motor:1.8KW
          Air consumption:0.7---0.8(different fabric,different air consumption)
          R.P.M :750-800


If you send us enquiry, please tell us details like following

Fabric width:190cm
Fabric warp and weft density:68*68
Fabric weave: satin


JLH9200 air jet loom configuration
  Item name Brand performance remark
1 electric equipment Inovance-China Latest model
2 feeder special for jinlihua double nozzle/four nozzle/six nozzle Exploration eye and electromagnetic needle imports
3 magnetic valve and nozzle SMC  Jiete twin nozzle per valve
4 ELO & ETU Inovance-China
5 weft scissor   special for JLH425m Import
6 heald frame New Light brand-Made in China
7 motor China brand
8 roller seat positive easing You can move back and forth up and down, conducive to warp beam use new type
9 roll axis   solid beating special for JLH425m
10 oil seal special for JLH425m NOK-Japan
11 bearing in gear box   all import bearing
12 cam dobby by customer requirement  Changfang-China Staubli-Made in China
13 dobby by customer requirement  Changfang-China Staubli-Made in China
14 jacquard by customer requirement
15 weft feeder by customer requirement  Jinlihua-China ROJ-Made in China
16 electric equipment by customer requirement  inovance-China Nanjing Baina-China
  B&L-Europe card
    *If you have any suggestions on how this website and our services could be improved to serve you better, please do not hesitate to let us know.


Our Advantages

Advantage 1 Ultra-high strength rack.
Advantage 2 More balanced performance beating mechanism.
Advantage 3 More energy efficient new weft insertion system.
Advantage 4 Smarter electronic control system.
Advantage 5 Networked factory and remote technology applications.

FAQ

(1) Q: Are you a manufacturer or agency?
A: We are a professional manufacturer holding our own International Trade Department, for that can better understand customer's needs and offer a reasonable price.

(2) Q: Are you available for on-the-spot invitation?
A: We do welcome our new and old friends come here to have a visitation. Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.

(3) Q: Is the price offered changeable?
A: We offer reasonable price for every client, and the price is changeable according to purchasing amount.

(4) Q: How about the quality?
A:The main subassembly and raw materials are all supplied by large companies. Key parts are research and developed by our own staff. Professional assembly line work and strict quality test system can ensure your high quality requirement.

(5) Q: How's the after-sale service?
A: We offer engineers available to service overseas under merchandiser's supervision and translation.

(6) What about the delivery time?
A: General delivery time is 20 days or so for one container after we recieved your downpayment.If the order is less and we have stocks also,the delivery time is 10 days or so.If our factory is busy,then we will negotiate the time according to our production plan.
