Basic Info.
Model NO.
AL
Transport Package
Carton
Specification
phenolic, aluminum/color steel/galvan steelized
Trademark
W. T
Origin
Jiangsu, China
Production Capacity
10000 Sqm/Day
Product Description
| Item No. | Thickness of foil (micron) | Fiberglass Weight | Thickness(mm) | Width(Meter) | Weave |
| AL-75 | 7/14/18/25/38/50 Aluminized film F.R Alum.Foil | 75g/m² | 0.12mm | 1/1.2/1.5m | Plain |
| AL-85 | 85g/m² | 0.12mm | 1/1.2/1.5m | Plain | |
| AL-95 | 95g/m² | 0.14mm | 1/1.2/1.5m | Plain | |
| AL-110 | 110g/m² | 0.15mm | 1/1.2/1.5m | Plain |
| AL-7628 | AL-3732 | AL-FW600 | AL-HT2025 | AL-3784 | AL-84215 | |
| Weave | plain | 3x1 twill | even grain check | plain | 8 HS satin | plain |
| Warp(per/cm) | 17.3 | 18 | 15 | 8 | 18 | 8 |
| Weft(per/cm) | 12.5 | 13 | 15 | 5.7 | 13 | 6 |
| Weight(g/m²) | 200 | 430 | 600 | 610 | 880 | 300 |
| Thickness(mm) | 0.2 | 0.43 | 0.55 | 0.75 | 0.9 | 0.38 |
| Coating | Aluminum foil/Metalized film | |||||
| Coating Thickness(micron) | 7/18/25 | |||||
| Width(m) | 1/1.2/1.5 | |||||
| Service temperature | fiberglass:550ºC/while mucilage:300ºC | |||||
