Fiberglass Multi-Axial Traxial Fabrics: Track Communication, Wind Electric Power

Fiberglass Multi-Axial Traxial Fabrics: Track Communication, Wind Electric Power. We are a factory specializing in high-quality fiberglass fabrics for communication and renewable energy applications.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
ETW
Certification
CCS,Dnv,Ios,SGS,RoHS
Transport Package
Brown Box and Pallets
Specification
50kg/CTN
Trademark
Tianma
Origin
China
HS Code
70194000
Production Capacity
10000 Tons/Year

Product Description

Fiberglass Multi-Axial Traxial Fabrics: Track Communication, Wind Electric Power

MULTI-AXIAL FIBERGLASS FABRIC

Product Description:
Multi-axial fiberglass facrics are made from rovings. The rovings placed parallel in each layer in a designed direction could be arranged 2-6 layers, which are stitched together by light polyester threads. The general angles of the placing direction are 0,90,± 45 degree. Unidirectional knitted fabric means main mass is in a certain direction, for example 0 degree. It is applied for vacuum infusion or winding process and mainly used for the production of wind blades, pipes, and so on. They are available for epoxy(EP), polyester(UP), and vinyl resin (VE) systems.

Product Features:
1,Good Mouldability
2,Stable resin speed for vacuum infusion process
3, Good combination with resin and no white fiber (dry fiber) after curing

Technical Specification:
MODEL GLASS TYPE RESIN SYSTEM TOTAL WEIGHT AREA WEIGHT (g/m2)
(g/m2) +45° 90° -45° MAT YARN
ETW800 E EP/UP/PU 811.8 394 200.4 11 200.4 / 6
ETW1200 E EP/UP/PU 1176.1 567 300.6 1.91 300.6 / 6
ETW1180 E EP/UP/PU 1168.6 661.4 250.6 1.91 250.6 / 6
ETF800 E EP/UP/PU 810.3 1.91 200.4 401.6 200.4 / 6
ETF1050 E EP/UP/PU 1055.9 1.91 217 614 217 / 6
ETF1200A E EP/UP/PU 1214.6 1.91 400.8 405.1 400.8 / 6
ETF1200A E EP/UP/PU 1358.8 1.91 300.6 640 300.6 / 6

Package & Storage:
The fabrics should be stored away from heat and moisture, and in their original packaging. The best conditions are : temperatures between 15 and 35 , humidity between 35 and 65%. If the product is not stored under these specifications , it is advisable to condition it in  the workshop for at least 24 hours before use, to prevent condensation. The pallets can be stored in 2 levels(1/1).Tianma  recommends that the material be used according to FIFO(first in, first our)method. It is recommended the use of a spacer plae(10mm) between the pallets.

Application:
Fiberglass Multi-Axial Traxial Fabrics: Track Communication, Wind Electric Power
Fiberglass Multi-Axial Traxial Fabrics: Track Communication, Wind Electric Power
