Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat

Fiberglass Factory: Explore our Fibra De Vidrio, Biaxial Fabrics, PP Core Mat, and Infusion Mat products. High-quality materials for various applications.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Company Profile
Overview

Basic Info.

Model NO.
CORE MAT
Max Width
2800mm
Standard Size
36kg
Transport Package
Brown Box and Pallets
Specification
A
Trademark
ISO 9001, ISO 14001, CE, DNV. CCS
Origin
China
HS Code
70193900
Production Capacity
5000 Tons/Year

Product Description


Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat
Product Description


Biaxial Core Complex

Product No. Overall Density 0º Roving   Density 90º Roving density Core Density Chop Density Polyester Yarn Density
(g/m2) (g/m2) (g/m2) (g/m2) (g/m2) (g/m2)
EWF600P180M300 1092 330 270 180 300 12
EWF600P180M600 1392 330 270 180 600 12
EWF800P180M450 1442 412 387 180 450 12

Core Combo Mat(Combiflow)

Product No. Overall Density 1st Chop Density Core Density 2nd Chop Density Polyester Yarn Density
(g/m2) (g/m2) (g/m2) (g/m2) (g/m2)
ES300P180M300 800.85 300 180 300 20.65
ES300P250M300 870.65 300 250 300 20.65
ES450P180M450 1100.65 450 180 450 20.65
ES450P250M450 1170.65 450 250 450 20.65
ES600P180M600 1400.65 600 180 600 20.65
ES600P250M600 1470.65 600 250 600 20.65
ES750P250M750 1770.65 750 250 750 20.65

Technical Data:

Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat
Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat

Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat
Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat

Company Profile
Changzhou Tianma Group Corporation was bulit in 1960 .It is one of the earliest research and production unit raw materials and products of glass fiber reinforced platic in China.
Products Yearly capacity
Fiberglass roving  20,0000mt
Fiberglass fabric and mat 5,000mt
Unsaturated polyester resin  200,000mt
FRP products 20,000mt
Vinyl ester resin  5,000mt
Adhesive  2,000mt
Sheet molding compound 10,000mt
Fiberglass wall covering  3000,000sqm
Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat

Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat
Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat

Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat
Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat
Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat



FAQ
Q: Are you a factory or trading company?
A: We are a group enterprise ,a professional fiberglass fabrics manufacturer from 1960,doing kinds of
fierglass composites and relative chemicals ,like UPR RESIN, VINYL ESTER RESIN,ETC.

Q:Where is your factory located? How can I visit there?
A: Our factory located in Xinbei district, Changzhou city, Jiangsu province. About 2 hours from Shanghai(air
port and train station), All our clients, from home or abroad, are warmly welcome to visit us!

Q: Can you OEM?
A: Yes, we can do not OEM products but also ODM. It's no problem.

Q: How can you guarantee your quality?
A: Quality is priority. Zhongjie people always attach great importance to quality con trolling from the very
beginning to the very end.
1. All raw materials we used are made by ourselves.
2. Skillful workers care every details in production, packing, transporting.

Q: What is your lead time?
A: Always in 7-10 days for normal production and stock in 3-5 days.

Fibra De Vidrio, Fiberglass Biaxial Fabrics PP Core Mat, Infusion Mat
