Fire Blanket High Silica Fiberglass Welding Blanket Fabric

Find high-quality fire blanket high silica fiberglass welding blanket fabric at our factory. We offer durable and reliable products for your welding needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
HTDFC
Color
White
Transport Package
Carton Pallet
Specification
100-1755 gsm
Trademark
HONTED
Origin
China
HS Code
7019
Production Capacity
1000000 Square Meters

Product Description

E Glass Fiberglass cloth also called fiberglass fabric which is an engineering material, which has the excellent merit such as anti-burns, anti-corrosion, stable-size, heat-isolation, minimum elongated shrinkage, high intensity, this new material product has already covered many domains such as electric appliances, electronic, transportation, chemical engineering, architectural engineering, heat insulation, sound absorption, fire prevention and environmental protection, etc.

Fiberglass Fabric has: plain weave, twill weave, satin weave, gauze weave.
a).Plain weave:  it can be used in electricity insulation materials and reinforced materials in industry, because of inseparable structure, plain and clear lines. 100gsm-800gsm
b).Twill weave: compared with plain weave, it is of high density, high intensity, with a soft and loose structural weave. It can be used in ordinary reinforced materials, filter materials, and painting cloth.
c) Satin weave: compared with plain weave and twill weave, it is of high density,high intensity, with a soft and loose structural weave with a good texture. It is applicable for use as a higher reinforced material in machinery.
d).Gauze weave: said lattice twist weave. It can be used in spread model curtain,resin reinforced emery wheel gray cloth and lattice embed belt.



Fire Blanket High Silica Fiberglass Welding Blanket Fabric
Fire Blanket High Silica Fiberglass Welding Blanket Fabric



High Temperature Proof Fiberglass Fabric

Thicker, heavier and stronger. Provides better durability light and far more resistance to heat impact from welding sparks as compared to other thinner and textured clothes. Non hairy texture preventing irritation to be exposed skin common in other fabric and asbestos clothes. Reduce the overall impact temperature and prevent burn through.

Temperature resistance capability of up to 550°C and can sustain even higher temperature sparks intermittently. Provides better durability, when subjected to heat shock treatments, Soft and flexible, making it ideal for wrapping around uneven surfaces and equipments.


Fire Blanket High Silica Fiberglass Welding Blanket Fabric
Fire Blanket High Silica Fiberglass Welding Blanket Fabric



High Silica Fiberglass Fabrics:



High silica fiberglass is inorganic fiber which contents more than 96% of SiO2. It is materials of high temperature resistance for fireproof protective cloth, fireproof curtain, fire blanket, protective materials for welding, filter for molten metal, dust collecting in media of high temperature gas and filtration in media of high temperature liquid,etc.

High temperature properties:

Soft point nearly 1700 deg, It can work 10 minutes at 1450 deg

Keep good state at 1600 deg for 15 seconds.

Long period service at 1000 deg for working temperature.

Excellent ability: low thermal conductivity, good chemical stability,

Good electric insulation, low thermal shrinkage.

Fire Blanket High Silica Fiberglass Welding Blanket Fabric



Silicone Rubber / PU Coated Fiberglass Fabrics:

Fire Blanket High Silica Fiberglass Welding Blanket Fabric
SIlicone Rubber / PU coated fiberglass cloth is a high performance fiberglass cloth, which possesses the properties of temperature resistance, anti-corrosion, high strength and made by rolling or impregnation with organic rubber. It is a newly made product with properties and many uses.



Specifications

Item Weave Weight (g/m2) Thickness Width Roll Length Color
E/C 01 Plain 105 ± 5 0.1mm 0.9-2.2m 300m white
E/C 012 Plain 120 ± 5 0.12mm 0.9-2.2m 300m white
E/C 014 Plain 140 ± 5 0.14mm 0.9-2.2m 300m white
E/C 016 Plain 160 ± 5 0.16mm 0.9-2.2m 300m white
E/C 018 Plain 180 ± 5 0.18mm 0.9-2.2m 300m white
E/C 260 Plain 260 ± 5 0.25mm 0.9-2.2m 200m white
E/C 320 Plain 340 ± 5 0.30mm 0.9-2.2m 100m white
E/C 7628 Plain 200 ± 5 0.18mm 0.9-2.2m 100m white
E/C 3732 Twill 430 ± 5 0.43mm 0.9-2.2m 100m white/yellow
E/C 600 Plain Pane 600 ± 5 0.55mm 0.9-2.2m 50m white/yellow
E/C 3784 Satin 840 ± 5 0.80mm 0.9-2.2m 50m white/yellow
E/C 3788 Satin 1750 ± 5 1.65mm 0.9-2.2m 50m white/yellow

Fire Blanket High Silica Fiberglass Welding Blanket Fabric
Fire Blanket High Silica Fiberglass Welding Blanket Fabric
Fire Blanket High Silica Fiberglass Welding Blanket Fabric


Storage

Unless otherwise specified, the fiberglass products should be in dry, cool and moisture-proof area. The room temperature and humidity should be always maintained at 15ºC~35ºC and 35%~65%. It is best if the price is used within 12 months after production date. The fiberglass products should remain in their original packaging until just prior to user.

Application

Fire Blanket High Silica Fiberglass Welding Blanket Fabric

FAQs

1. What is your terms of packing?
    Generally, we pack our goods in carton with pallet

2. What is your tems of payment?
    T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

3. What is your terms of delivery?

    EXW, FOB, CFR, CIF,L/C at sight

4. How about your delivery time?

    Generally, it will take 21 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

5. Can you produce according to the samples?

Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

6. What is your sample policy?
    We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

7. Do you test all your good before delivery?
    Yes, we have 100% test before delivery
