Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub

Shop for high-quality 3500lbs H545-2A idler trailer wheel hub at our factory. Reliable 5-bolt design ensures durability and safety on the road.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Packaging & Shipping
  • FAQ
Overview

Basic Info.

Model NO.
H545-2A
Type
Front Axles
Transport Package
Wooden Box
Specification
5.5kg
Origin
Zhejiang, China
HS Code
8708507990
Production Capacity
5000PCS/Month

Product Description

Trailer parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub
Product Features
The trailer hub is the main fixing device that provides mounting points for wheel rotation. There are idler wheel hubs and brake wheel hubs. The idle wheel hub has no braking ability and can only rotate freely. The brake hub contains trailer brakes, whether electric or hydraulic.
Personnel 545-2A
Bt Idler 5 bolts 4.5 "BC
3500 pounds
Hub+bolt+nut+bearing outer ring 44610/68111+bearing inner ring 44649/68149+seal+dust cover
What is a trailer hub?
The trailer hub is the main fixing device providing wheel rotation mounting points. There are idler wheel hubs and brake wheel hubs. The idle wheel hub has no braking ability and can only rotate freely. The brake hub contains trailer brakes, whether electric or hydraulic.
Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub Trailer Hub and Drum

Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub
How to replace the trailer hub? How to replace the trailer hub?
1. Remove the wheel
Remove the lug nut and wheel. Ensure that the trailer is supported by a jack bracket and the other wheel is blocked.
2. Remove the dust cover
Use a large screwdriver to pry open the dust cover.
3. Remove the split pin
Straighten both ends of the cotter pin and pull it out with Needle-nose pliers.
4. Remove the wheel hub
Remove the fixing nut and washer, and then pull the hub off the spindle. Be careful that the trailer bearings may come off the wheel hub. Place the bearing on a clean newspaper.
5. Remove the rear bearing and seal
Remove the rear bearing and seal, and use a wooden block and hammer to strike along the edge of the bearing. If the seal on the back of the wheel hub rusts, spray a little WD-40 on the back to help loosen it. If the seal is damaged, replace it. Use a brush to clean all grease on the bearings, races, and seals in a small can of kerosene. Check them for signs of wear, and if any signs of wear are suspected, replace them. After cleaning the bearings and parts, spray brake cleaner and let it dry on one side. Wipe the inside of the spindle and hub with a clean cloth, remove all grease, and clean with brake cleaner.
6. Install lubricating grease into the bearing
Push the grease into the bearing from the wide side. Continue to push the grease into the drum until the holder and drum are full. Next, apply lubricating grease on the inside of the wheel hub. Use a wooden block and hammer to knock the seal back onto the rear of the hub, and then install the hub and bearing back onto the spindle.
7. Reassembly of the wheel hub
Screw the nut back onto the spindle and turn it clockwise. Rotate the hub several times when tightening to ensure the bearings are correctly seated. Tighten the nut. Now back off the nut by approximately one eighth of a turn until the hole on the spindle aligns with the space in the nut. Push in a new cotter pin (available at Hardware stores and auto parts stores) and bend the end of the cotter pin to prevent it from falling off. Gently knock the dust cover back into place. Apply anti-seize compound to the lug threads, reinstall the wheel, and tighten the nuts. Perform the same operation on each wheel.
Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub
Certificates and Honors
Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel HubTrailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub

Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub
Packaging & Shipping

Trailer Parts 3500lbs H545-2A Idler 5 Bolts Trailer Wheel Hub

FAQ

Q: Are you trading company or manufacturer ?
A: Our group consists in 3 factories and 2 abroad sales corporations.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: How long is your delivery time ? What is your terms of payment ?
A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment.
Q: What is the exact MOQ or price for your product ?
A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation. If you have another question, please feel free to contact us.
