Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs

Shop our high-quality Udtm fiberglass fabric combination mats, including Udtm 225/225, Udtm 300/300, and Udtm 600/300, at our factory direct prices.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Features
  • Product Parameters
  • Packaging & Shipping
  • Storage
  • Application
Overview

Basic Info.

Roll Width
200 mm - 2600 mm
Roll Length
20-50 Kg / Roll
Production Time
14-21 Days
Application 1
Oil Pipe, Tank, Boat, Yatch
Application 2
Rtm, FRP Hull, Car Shell
Application 3
Pipeline Industry, Auto Parts, Radomes, Cables E
Transport Package
Carton Pallet
Specification
200-1762g
Trademark
HONTED
Origin
China
HS Code
7019310000
Production Capacity
1000 Tons/Month

Product Description

Product Description

E Glass Fiberglass Unidirectional fabric is a stitch-bonded composite reinforcement combining continuous roving oriented in the 0°or 90°directions into a single fabricTwo layers of roving  With or without a layer of chopped strands  (0g/m²-300g/m²). It can be with mat or without mat It is ideal for applications such as wind blades, marine panel, snowboards, truck and trailer panel.


Woven roving combo mat is made of woven roving and chopped fiberglass strand complex of, then stitched together with polyester yarn. It is compatible with Polyester, Vinyl and Epoxy resin and widely used in boat building, Auto parts, refrigerated tools and structural sections industry etc, suitable for hand lay up, RTM, pultrusion, vacuum processes.
Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs
Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs


FIBERGLASS COMPOSITES MAT:

Glass fiber composite MAT is made of glass fiber-free roving yarn arranged in one-way parallel, the outermost layer is cut into glass fiber yarn or short-cut felt of a certain length, and is sewn with organic fiber.

Mainly used for FRP pullout RTM forming, hand lay up molding and other processes, the end products are mainly FRP hull, car shell, plate, profile and so on.

Fiber structure can be designed to provide high strength in a certain direction;

The fiber is not easy to produce displacement and deformation, easy to operate;

Fabric without any binder, easy to soak;

The compounding of the structure can reduce the layering and effectively improve the production efficiency.


Product Features

Easy shape adaptation
Easy impregnation
Excellent mechanical properties

No any Binder, good compatible with Multi-Resin

simplify the molding process

improve producing efficiency and decrease cost


Product Parameters

Specifications

Product No.

Overall
Density
(g/m²)

0º Roving
Density (g/m²)

90º Roving
Density (g/m²)

Chop Density (g/m²)

Polyester Yarn Density
(g/m²)

HTUDL300

312

261

39

/

12

HTUDL400

412

355

45

/

12

HTUDL460

469.5

413

47

/

9.5

HTUDL600A

612

533

67

/

12

HTUDL600

612

480

120

/

12

HTUDL800

812

710

90

/

12

HTUDL950

956

866

84

/

6

HTUDL1000

1022

710

/

300

12

HTUDL1200

1195

1134

55

/

6

HTUDT125

126

/

120

/

6

HTUDT300

309.5

/

300

/

9.5

HTUDT500

509.5

/

250

/

9.5

HTUDT600

609.5

/

600

/

9.5

        HTUDT700    709.5               /             700                      /                      9.5

UDTM225/225

459.5

/

225

225

9.5

UDTM300/300

609.5

/

300

200

9.5

UDTM600/300

909.5

/

600

300

9.5

Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs
Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs


Roll width


Standard width in 1250mm, 1270mm, and other sizes depends on customer's real needs, available in 200mm to 2600mm.


Packaging & Shipping



Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs
Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs
Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs

                Inner side Plastic Film                                              Carton + Non wooden Pallet                                                       Container Loading


Storage

Unless otherwise specified, the fiberglass products should be in dry, cool and moisture-proof area. The room temperature and humidity should be always maintained at 15ºC~35ºC and 35%~65%. It is best if the price is used within 12 months after production date. The fiberglass products should remain in their original packaging until just prior to user.


Application

Automotive, vessels, gratings, bathtub, FRP composite, tanks, waterproof, reinforcement, insulation, spraying, spray gun, mat, gmt, boat, csm, frp, panel, car body, knitting, chopped strand, pipe, gypsum mold, boat hulls, wind energy, wind blades, fiberglass boat hulls, boats fiberglass, fiberglass pools, fiberglass fish tank, fiberglass fishing boat, fiberglass molds, fiberglass rods, fiberglass swimming pool, fiberglass boats molds, fiberglass pool, fiberglass chopper gun, fiberglass spray gun, fiberglass water tank, fiberglass pressure vessel, fiberglass poles, fiberglass fish pond, fiberglass resin, fiberglass car body, fiberglass panels, fiberglass ladder, fiberglass insulation, fiberglass dinghy, fiberglass car roof top tent, fiberglass statue, fiberglass grating, fiberglass rebar, glass fiber reinforced concrete, fiber glass swimming pool, etc.
Udtm 225/225, Udtm 300/300, Udtm 600/ 300, 90 Degree Unidirectional Fiberglass Fabric Combination Mat, Unidirectional Mat 50 Inch X 110 Lbs

FAQs

1. What is your terms of packing?
    Generally, we pack our goods in carton with pallet

2. What is your tems of payment?
    T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

3. What is your terms of delivery?

    EXW, FOB, CFR, CIF,L/C at sight

4. How about your delivery time?

    Generally, it will take 21 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

5. Can you produce according to the samples?

Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

6. What is your sample policy?
    We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

7. Do you test all your good before delivery?
    Yes, we have 100% test before delivery
